The RANCHER® SERIES

The RANCHER® is a professional firefighter-grade system that comes with top-of-the-line components including the powerful, durable MINI-STRIKER® pump and the proven Hannay hose reel. It provides the strength and performance you need to move water. It is ideal for rapid intervention in remote areas that can’t easily be reached by larger vehicles, and comes with 65- or 125-gallon tank capacity.

Features

  • TANK 125 US gal (473 L) OR TANK 65 US gal (246 L)

    Lightweight polyethylene
    Secured with galvanized steel tank bands
    Robust cap with retention clip
    Tank side water level indicator

  • WATERAX PUMP

    Close coupled single stage premium centrifugal pump end
    Anodized pump parts for corrosion resistance
    Governor system for overspeed protection
    Easy to use Honda 4-stroke engine
    US Forest Service approved spark arrestor

  • MANUAL REEL

    Ultra-durable aluminum alloy
    Standard booster hose

    3/4” x 50’ (19 mm x 15.2 m)
    6-14 US gal/min (23-53 L/min)
    CORDOVA nozzle

  • PLUMBING

    Non-corrosive polypropylene piping
    1.5” (38 mm) discharge valve w/cap and chain
    1.5” (38 mm) overboard suction port w/cap and chain
    Pump to tank re-circulation line (bypass)
    Pressure gauge

  • FOAM SYSTEM

    Optional foam eductor/mixer

  • LOW MOUNT BASE

    Robust co-polymer polypropylene Rails
    Four cut-outs for easy lifting

1 6

Technical Specs

  • Engine Specifications

    Engine - Honda® GXH50 4-cycle, air-cooled, single cylinder, OHV
    Maximum power - 2.5 hp (1.9 kW)
    Displacement - 49.4 cc (3.01 cu in)
    Starting system - Recoil starter
    Ignition - Transistorized magneto
    Governor - Mechanical
    Lubrication - Oil, splash
    Fuel type - Gasoline (unleaded, 86 minimum octane, 10% max. ethanol)
    Fuel consumption - 0.17 US gals/hr (0.65 L /hr)
    Emissions compliant - engine is CARB and EPA certified

  • Pump End Specifications

    Close coupled single stage premium centrifugal pump end
    Lightweight aluminum alloy pump components
    Anodized pump parts for corrosion resistance
    Foam compatible
    Stainless steel pump shaft
    Mechanical rotary seal

1 2
