Drago-ISI Inc.
Drago-ISI Inc. (Drago Engineering and Fire Safety) specializes in the design and marketing of innovative solutions for fire control and water conservation. The Drago simplicity, efficiency and capability to flow to a maximum of 785Us gpm (2973 L/Min with a projection/distance exceeding 200 feet (60 meter).
The Drago uses our constant spray technology unlike any other fan cannon on the market. The unique center nozzle (Spider) design provides a smooth performance curve with optimal water flow and droplet quality settings compared to all other fan technologies.
It’s versatility to effectively stream a mixture of water / air / water + firefighting agent (foam or even encapsulating agents) at a great distance, in order to effectively carry out various maneuvers aimed at extinguishing the fire, cooling the surrounding air, slowing down the progression of the fire or the dispersal of smoke and toxic fumes.
The technology behind the Drago Spider.
One strategy for using water with improved efficiency and speeding up fire extinguishing for a given water flow rate would be to divide the flow into a large number of fine droplets distributed over a large area of the flaming mass. When the water is broken into small particles, it absorbs heat and converts into steam more rapidly because more of the waters surface is exposed to the heat in order to promote rapid evaporation.
Spraying water on a burning material is a common way to lower the temperature of the flaming mass to extinguish the fire. Directing straight streams of water at the base of a fire is not a very effective way of fighting the fire. One indication of this, is the large volume of water surrounding a site after fighting a fire. causing additional damage to the remaining structure and large firewater contaminate runoff into the environment and water treatment facility.
Indeed, one of the most useful properties of water for extinguishing a fire is its great capacity for absorbing heat. In particular, thanks to its unrivaled latent heat of evaporation. Therefore, water that does not evaporate is not used efficiently, besides being a source of collateral damage.
Technical Data.
-
Main features
- Spider all aluminum and anodized for lightness and extended life
- Central module (Spider) varying from (50 to 275 psi | 3.45 to 19 Bars) for all types of conditions
- Hybrid spray (air / water) in aerosol for 3x better thermal absorption in optimal fragmentation
- Single fragmentation curved tip for long distance spraying
- Fragmentation screen, foam / encapsulator (3.8 inches | 96.5 mm) for optimal expansion
- Easy connection with indicator, 2 ½ inches | 63.5 mm, NST for quick coupling
- Water flow between (40 to 785 GPM | 182 to 3,568 liters / minute) for superior water savings
- Water projection distance (100 to 200 feet | 30.5 – 60.9 m) and more to reach summits
- Water / foam (1%) / encapsulator projection distance, (100 to 180 feet | 30.5 to 54.8 m) to cover summits
- Water penetration width greater than .100 feet | 30 m (30 to 40 feet | 9.1 to 12.1 m) for maximum overlap
- Width of penetration (1%) foam / encapsulator, more than, 100 feet | 30 m (40 to 50 feet | 12.1 to 15.2 m) for maximum removal
- Operational in cold or hot weather for hassle-free outdoor use
- Installation bar for optimal grip
- Installation indicator for quick installation
- No maintenance for easy maintenance
-
Technical data
- Height 18.2 – 22 in | 46.2 – 22 cm
- Diameter 21.3 – 23.8 in | 54.1 – 60.4 cm
- Number of nozzles 14 – 16 nozzles
- Central module (Spider) Blue std 14 nozzles
- Weight 18 lbs
- Central module (Spider) Blue with diffuser screen 14 nozzles
- Weight 19 lbs
- Central module (Spider) Red std 16 nozzles
- Weight 18.5 lbs
- Central module (Spider) Red with diffuser screen 16 nozzles
- Weight 19.5 lbs
- Central module (Spider) Green std 14 nozzles
- Weight 18 lbs
- Connection Spider 2 ½ ” | 64 mm / NST
- Water pressure (40 – 275 psi | 2.75 – 18.9 Bars)
- Water flow 181.8 – 3568.6 liters | minute | 40 – 785 GPM
- Droplet between 500 and 1000 micron
- Complete anodization
- No filtration or maintenance system
- Quick installation indicator
- 1 year warranty
Applications by Building Type
Small buildings and large surfaceHeritage buildings, Schools, Hospitals, Home centers, Supervised residences, Detention facilities, Churches, Museums, Libraries, Warehouses with dangerous materials, Paint factories or Chemical oil industries, Government / Defence, Agricultural buildings, Shopping malls, Service stations.
High-riseHotels, Office buildings, Condos, Residential buildings with 9 or more dwellings
ServicesWater treatment plant, Subways, Tunnels, Parking Lots, Mines.
TransportAirport, Port facilities, Rail sector, Road transport.
WildlandParks, Forest reserves, Outfitters, natural resources, Cities & Municipalities, Industries.
ResidentialSingle family home 2 or 3 floors and large surface residences.
High-hazardAircraft hangars, Grain elevators, Oil refineries, Plastics manufacturing facilities, Sawmills
